3. General
RGBS
Defines a conn ection with four signals, to transmit video and sync information. Vertical and hor izontal sync are com bined on a single
channel.
RGsB
Defines a connection with three signals, to transmit video and sync information. Here, the sync inform ation is transm itted on the
green channel.
Scaler
An elec tronic circuit that reduces or enlarges source images, thus creating PIPs a nd Keys that can be pos
itioned (and trans itioned).
SD-SDI (Standard Definition Serial Digital Interface)
SD-SDI is a s tandard d efinition SDI signal with a data rate of 270 Mbit/s only (SMPT E 259M). E xample f ormats are 480i and 525i.
SDI (Serial Digital Video)
A d igital representation of the v ideo signal that is distributed v ia a single coaxial c able with BNC connec tors.
System
Refers to E2.
T-Bar
Also known a s a Fader, the T-Bar is the lever on a switcher that manually controls the progress of an effect. The p osition of the fader
controls the amount of the BG (Background) Bus signal and the PV W (Preview) Bu
s signal that contributes to the mix, wipe or key.
Wipe
A Wipe is a transition between two video sou rces that uses a s elected pattern to determine the edge between the two sources.
Y/C
Y/C is a video signal in which color and brightness information is transmitted separately (luminance Y, chrominance C).
