10. Maintenance
Image 10-73
7. Remove the c able from th e unit.
How to install the Genlock Cable
To install the Genlock Cable follow th e same procedure in the reverse order.
There is a key on t he c onnector to prevent incorrect insertion of the cable.
Make sure the latches are fully e ngag ed to prevent the cab le from coming loose.
R5905948 E2 12/12/2014 263
