4. Hardware orientation
Slot Card type Connectors
11
HDMI O utput Card 4x HDMI connectors per 1.4a specifications
12 HDMI O utput Card 4x HDMI connectors per 1.4a specification s
13 6G S DI O utput Card 4x B NC connectors supporting up-to 6G S DI
The following sec tions describe each type of card in detail:
• "HDMI O utput Card", page 41
• "6G S DI Output Card", page 42
Multiviewer (MVR) card
Physically, the Multiviewer c ard is identical to the HDMI output card but when it’s plugged in the last slot
it operates as a M ultiviewer
supporting 4 monitors. The M ultiviewer c ard is a dedicated f ully integr ated mon itoring solution allowing multiple displays to be shown
together on a single display. Up to 64 MVR windows (Sources, backgrounds, clock or destinations) c an be displayed across all 4
outputs.
The user can select from the G UI M ultiviewer p age from predefined layo uts, or create customize layouts, texts, backgrounds, borders
or colors of the monitors. T he MVR includes seve ral alarms such as Frozen and Loss-of-Signal indicators. For more de tails on
Multiviewer features, refer to the section "M ultiviewer (M VR) Me nu", page 134
Slot Card type Connectors
14
HDMI Multi-viewer Card 4x HDMI connectors per 1.4a specification
34
R5905948 E2 12/12/2014
