4. Hardware orientation
Specifi ca tions
• DVI 1.0 Specification
• Maximum H Active: 4,096, Maximum V Active: 3,072
• Supported format:
- All single link DVI formats up to 165 MHz
- All d ual link DVI formats up to 330 M Hz
- 4K/UHD Supported:
o
3,840x2,160/ 23.98/24/25/29.97/30 input via 1x DVIDL, 2x DV ISL (L and R half) or 4x DVISL (quadrants)
o
3,840x2,160/ 50/59.94/60 input v ia 2x DVIDL (L and R half) or 4x DVISL (quadrants)
o
4,096x2,160/ 23.98/24/25/29.97/30 input v ia 2x DVISL (L and R half) or 4x DVISL (quadrants)
o
4,096x2,160/ 50/59.94/60 input v ia 2x DVIDL (L and R half) or 4x DVISL (quadrants)
o
4,096x2,400/ 23.98/24/25/29.97/30 input v ia 2x DVISL (L and R half) or 4x DVISL (quadrants)
o
4,096x2,400/ 50/59.94/60 input via 2x DVIDL (L & R half) or 4x DV ISL (quadrants)
- EDID version 1.3 compatible
- HDCP version 1.4 c ompatible
DVI
Digital Visual Interface is a display interface developed in re sponse to the proliferation of digital flat panel displays.
The digital video connectivity standard that was developed by DDW G (D igital Display Work Gr oup). This connection
standard offers two different connectors: one with 24 pins that handles digital video signals only, and one with 29 pins
that hand les both digital and analog video. This standard uses TMDS (Transition Minimized Different
ial Signal) from
Silicon Image and DDC (Display Data Channel) from VE SA (Video Electronics Standards Ass ociation).
DVI can be single or dual link.
38 R5905948 E2 12/12/2014
