© 06/2006 8166-001
5/6
TCD 2015
Drive system
W 02-02-04
6
z Tighten screw (1) until the assembly sleeve (2) is
touching.
z Remove assembly tool.
1
2
© 35206-2
z Check installation depth (1) with depth measuring
appliance.
P03 26
1
© 35201-3
z Remove flanged hub with torsional vibration damper
and V-belt pulley.
z Lightly oil screws (1).
z Tighten all screws (1) alternately.
A12 030
Block flywheel with suitable tool.
1
© 40659-0
