Deutz TCD 2015 - Page 237

© 06/2006 8178-001
9/14
TCD 2015
Crankcase
W 03-08-01
6
z Mount holder.
z Fasten all screws (1).
TIghten screws only after mounting the
connecting pipe.
1
© 40539-0
z Tighten screws alternately.
Screw length:
M10 x 70 mm (1)
M10 x 110 mm (2)
2
1
1
© 40538-0
z Tighten screws alternately.
 A03 020
