TCD 2015
Engine control
W 04-05-05
6
z Unscrew all screws (1).
z Remove cover (2) .
z Remove gasket.
1
2
© 40425-0
z Insert counter support (1) in the toothing of the cam-
shaft gear wheel.
1
© 40426-0
z Turn the camshaft gear wheel in the direction of
the A-bank.
z Block the camshaft gear wheel with the counter hold-
er on the crankcase (arrow).
© 40427-0
