Deutz TCD 2015 - Page 324

TCD 2015
Engine control
W 04-05-07
© 06/2006 8189-001
4/32
6
z Unscrew screws (1).
z Remove cover (2) .
z Remove cover (3).
1
3
2
© 40460-0
z Unscrew screws (1).
z Remove pad thrust bearing (2).
z Attach turning gear.
 W 04-06-03
1
2
© 40417-0
z Loosen all screws (1).
Concealed screws can be accessed by
turning the crankshaft with the turning gear.
1
© 40464-0
