TCD 2015 Railway
Exhaust system/Charging
W 06-06-04
© 06/2006 8204-001
2/6
6
z Unscrew screws (1).
z Remove oil return pipe (2).
z Remove gasket.
1
2
© 42050-1
z Loosen hose clip (1).
z Loosen hose clip (2).
2
1
© 42051-2
z Pull off tubing connection (1).
z Pull off bleeding hose (2).
z Remove breather pipe (3).
1
2
3
© 42052-2
