TCD 2015 Railway
Exhaust system/Charging
W 06-06-04
6
z Unscrew nuts (arrows).
z Remove turbocharger (1).
1
© 42053-1
z Unscrew screw-in nipple (1).
z Remove sealing ring.
z Visually inspect the components.
1
© 42054-1
Installing the turbocharger
z Mount new sealing ring.
z Tighten screw-in nipple (1).
 A12 098
1
© 42054-1
