© 06/2006 8211-001
5/6
TCD 2015 Railway
Fuel system
W 07-01-03
6
z Hold screw-in nipple.
z Tighten lock nuts (1).
A07 018
Attention!
Install fuel pipes tension free!
1
© 42022-1
z Position hose pipe (2).
z Mount new sealing rings.
z Tighten hollow screw (1).
A12 090
Attention!
Lay the hose pipe free from chafing and
tension.
1
2
© 42021-1
z Plug in the cable plug (1).
Ensure that the cables are connected pro-
perly.
1
© 42020-2
