Deutz TCD 2015 - Page 468

TCD 2015 Railway
Fuel system
W 07-01-04
© 06/2006 8213-001
2/4
6
z Unscrew union nuts (1).
z Remove fuel pipe (2).
1
1
2
© 42026-1
z Unscrew union nuts (1).
z Remove fuel pipe (2).
1
1
2
© 42028-1
z Hold screw-in nipple.
z Unscrew lock nut (1).
z Remove distributor (2).
z Visually inspect the components.
1
2
© 42029-1
