Deutz TCD 2015 - Page 47

4
© 06/2006 8145-001
27/28
TCD 2015
Technical data
Tightening specifications
A13 090 Cable harness holder to connecting pipe
M8 x 20 M8 x 16
TCD 2015 18 Nm
M8
TCD 2015 (Railway)
20 Nm
A13 094 Cable harness rail on holder
M6 TCD 2015 7.5 Nm
M6x12 M6x16
TCD 2015 (Railway)
8 Nm
A13 098 Holder (cable harness) on connection housing
TCD 2015 (Railway)
70 Nm
ID no. Name Screw type Notes / Remarks Series
Pre-clam- ping value
Post- clamping value
