Deutz TCD 2015 - Page 470

TCD 2015 Railway
Fuel system
W 07-01-04
© 06/2006 8213-001
4/4
6
z Tighten lock nuts (1).
 A12 080
Attention!
Install fuel pipe tension free.
1
1
© 42027-1
z Tighten lock nuts (1).
 A12 080
z Hold screw-in nipple.
z Tighten lock nut (2).
 A07 018
Attention!
Install fuel pipe tension free.
1
2
© 42030-1
z Position pipe clip.
z Tighten screw (2).
 A07 044
z Lay cable harness and fix with cable tie (1).
1
2
© 42025-1
