© 06/2006 8220-001
3/6
TCD 2015
Fuel system
W 07-07-02
6
z Select shim for setting the opening pressure.
z Insert shim.
The opening pressure depends on the
thickness of the shim.
A thicker shim gives a higher opening pres-
sure.
© 36274-2
z Insert compression spring.
© 33907-2
z Insert thrust bolt.
© 33908-2
