TCD 2015 Railway
Fuel system
W 07-10-06
© 06/2006 8224-001
6/6
6
z Plug in the cable plug (1).
z Plug in the cable plug (2).
2
1
© 45854-0
z Plug cable plugs (1) together.
z Fix cable with cable tie (2).
1
2
© 42108-1
z Plug in cables (1).
T13 054
z Tighten screws .
A13 054
Clamp all injection pumps.
Attention!
Note assignment and polarity of the electri-
cal connections!
Connect cables according to marks made
before removing.
1
© 45858-0
