z Read measured value at the intersection (arrow) of
the indicator arm and scale.
 P12 11
P12 21
z If the nominal value is not reached, the tensioning
process must be repeated.
Note different units on the scale.
© 45413-0
z Tighten screws (1).
 A13 012
1
© 40983-0
z Tighten nut (1).
 A13 017
1
