Fujitsu PRIMERGY RX2520 M4

RX2520 M4 Upgrade and Maintenance Manual 225
Expansion cards and backup units
9.5.1.4 Installing the FBU
Figure 132: FBU mounting positions
Ê The mounting positions are located on the air duct:
1FBU 1
2 FBU 2 or Dual microSD 64GB Enterprise
