390 Upgrade and Maintenance Manual
RX2520 M4
Appendix A
16.1.3 Server interior
Figure 275: Interior (example 3.5-inch HDDs)
Pos. Component
1 Up to 2 PSUs
2 Front panel module / dummy cover
3 ODD (option) / dummy cover
4 Up to 8x 3.5-inch HDDs / dummy modules
5 Fan modules
6CPUs
7 Main memory
8 PCI slots
