RX2520 M4
Upgrade and Maintenance Manual 371
System board and components
15.5.3 Replacing the M.2 SSD
15.5.3.1 Preliminary steps
Ê "Locating the defective server" on page 45
Ê "Shutting down the server" on page 48
Ê "Disconnecting the power cord" on page 49
Ê "Getting access to the component" on page 50
Ê "Removing the air duct" on page 61
Ê "Removing the crossbar" on page 65
Ê If applicable, "Removing an expansion card" on page 213
15.5.3.2 Replacing the M.2 SSD
Ê Remove the defective M.2 SSD, see section "Removing the M.2 SSD" on
page 369.
Ê Install the new M.2 SSD, see section "Installing an M.2 SSD" on page 365.
15.5.3.3 Concluding steps
Ê If applicable, "Installing an expansion card" on page 208
Ê "Installing the crossbar" on page 66
Ê "Installing the air duct" on page 62
Ê "Reassembling" on page 55
Ê "Connecting the power cord" on page 59
Ê "Switching on the server" on page 60
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
