272 Upgrade and Maintenance Manual
RX2520 M4
12.2.1.4 Concluding steps
Ê "Installing the front panel cage" on page 319
Ê "Installing the fan holder" on page 64
Ê "Installing the air duct" on page 62
Ê "Reassembling" on page 55
Ê "Connecting the power cord" on page 59
Ê "Resuming BitLocker functionality" on page 89
12.2.2 Removing a ODD
12.2.2.1 Preliminary steps
Ê Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
Ê "Suspending BitLocker functionality" on page 67
Ê "Shutting down the server" on page 48
Ê "Disconnecting the power cord" on page 49
Ê "Getting access to the component" on page 50
Ê "Removing the fan holder" on page 63
Ê "Removing the front panel cage" on page 313
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH1 / (+) No.1 screw driver
