RX2520 M4
Upgrade and Maintenance Manual 389
Appendix A
16.1.2 Server rear
Figure 274: Rear side
Pos. Component
1 Up to 2 PSUs / dummy cover
2 PCI slots 9
3 PCI slots 8
4 I/O panel
5 PCI slot 4
6 PCI slot 3
7 PCI slot 2
8 PCI slot 1
