27RX2520 M4
AccDrv_LTO
Cable plan
Power
Data
LTO
SAS Controller
slot2 (boot)
MLC2
MLC1
TFM
SAS Controller
Slot 1
MLC2
MLC1
TFM
Systemboard
D3386
PWR ODD
C38
