RX2520 M4
Upgrade and Maintenance Manual 299
12.4.3 Replacing a LTO drive
12.4.3.1 Preliminary steps
Ê Ask the system administrator to eject all remaining backup or optical media
from the backup or ODD before removing it from the server.
Ê "Suspending BitLocker functionality" on page 67
Ê "Shutting down the server" on page 48
Ê "Disconnecting the power cord" on page 49
Ê "Getting access to the component" on page 50
Ê "Removing the fan holder" on page 63
Ê "Removing the front panel cage" on page 313
12.4.3.2 Removing the defective LTO drive
Ê Remove the LTO drive, see section "Removing the LTO drive" on page 294.
12.4.3.3 Installing the new LTO drive
Ê Install the LTO drive, see section "Installing the LTO drive" on page 290.
12.4.3.4 Concluding steps
Ê "Installing the front panel cage" on page 319
Ê "Installing the fan holder" on page 64
Ê "Reassembling" on page 55
Ê "Connecting the power cord" on page 59
Ê "Switching on the server" on page 60
Ê "Resuming BitLocker functionality" on page 89
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
