Fujitsu PRIMERGY RX2520 M4 Upgrade And Maintenance Manual

4RX2520 M4
List of used cables (continuation)
Cable plan
Ref.
Part number
Name
Routing
Data Cables
C19
T26139-Y4040-V26
CBL SAS3.0A500
HDD Cabling 4/8x3.5" SATA
HDD Cabling 4/8x3.5" SAS
HDD Cabling 4/8x3.5" EP5x0
HDD Cabling 8/16x2.5" SAS w/ Exp
HDD Cabling 8/16x2.5" EP5x0 w/ Exp
HDD Cabling 24x2.5" SAS
HDD Cabling 24x2.5" EP5x0 w/ Exp
C20
T26139-Y4040-V25
CBL SAS3.0A720
HDD Cabling 4/8x3.5" SATA
HDD Cabling 4/8x3.5" SAS
HDD Cabling 4/8x3.5" EP5x0
HDD Cabling 8/16x2.5" SAS w/o Exp
HDD Cabling 8/16x2.5" EP5x0 w/o Exp
C21
T26139-Y4040-V38
CBL SAS3.0 500
HDD Cabling 12x3.5" SAS
HDD Cabling 12x3.5" EP5x0
C22
T26139-Y4040-V8
CBL HOST-BP 470
HDD Cabling 8x2.5" SATA
HDD Cabling 8/16x2.5" SAS w/o Exp
HDD Cabling 8/16x2.5" EP5x0 w/o Exp
C23
T26139-Y4040-V9
CBL HOST-BP 540
HDD Cabling 8x2.5" SATA
HDD Cabling 8/16x2.5" SAS w/o Exp
HDD Cabling 8/16x2.5" EP5x0 w/o Exp
C24
T26139-Y4040-V10
CBL HOST-BP 620
HDD Cabling 8/16x2.5" SAS w/o Exp
HDD Cabling 8/16x2.5" EP5x0 w/o Exp
C26
T26139-Y4040-V30
CBL_SAS30_RAL_150
HDD Cabling 8/16x2.5" SAS w/ Exp
HDD Cabling 8/16x2.5" EP5x0 w/ Exp
HDD Cabling 24x2.5" SAS
HDD Cabling 24x2.5" EP5x0 w/ Exp
C27
T26139-Y4040-V31
CBL_SAS30_RAL_180
HDD Cabling 8/16x2.5" SAS w/ Exp
HDD Cabling 8/16x2.5" EP5x0 w/ Exp
HDD Cabling 24x2.5" SAS
HDD Cabling 24x2.5" EP5x0 w/ Exp
C28
T26139-Y4040-V32
CBL_SAS30_RAL_210
HDD Cabling 24x2.5" SAS
HDD Cabling 24x2.5" EP5x0 w/ Exp
C29
T26139-Y4040-V33
CBL_SAS30_250_RAL
HDD Cabling 8/16x2.5" SAS w/ Exp
HDD Cabling 8/16x2.5" EP5x0 w/ Exp
HDD Cabling 24x2.5" SAS
HDD Cabling 24x2.5" EP5x0 w/ Exp
C31
T26139-Y4039-A80
CBL USB3.0AN 0,8M
AccDrv_RDX
C34
T26139-Y2361-V103
CBL_HDD_SIGNAL_220
RAID EP5x0 - TFM FBU345 - HDD Signal
C35
T26139-Y4049-V2
CBL_B100SD_ANG_400
Dual_Micro_SD_64GB_Enterprise
C36
T26139-Y4018-V8
CBL_I2C_ROC_330
Dual_Micro_SD_64GB_Enterprise
C37
T26139-Y4015-V612
CBL_VPP_320+50
PCIeSSD Cabling 8x2,5" + 4x2.5" Retimer
C38
T26139-Y4044-V2
CBL_SAS_DEV_PWRSIG
AccDrv_LTO
C43
T26139-Y4050-V7
CBL_OCU_OCU_820
PCIeSSD Cabling 8x2,5" + 4x2.5" Retimer
C44
T26139-Y4040-V75
CBL_SAS30_AP200
PDUAL AP200
