Fujitsu PRIMERGY RX2520 M4 Upgrade And Maintenance Manual

RX2520 M4 Upgrade and Maintenance Manual 351
System board and components
15.3 Trusted Platform Module (TPM)
There are different TPM kits available. The procedures of installing, removing
and replacing are identic.
Figure 246: TPM installation kit - example 1
Figure 247: TPM installation kit - example 2
1 TPM (Trusted Platform Module) 3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
0
1
2
