Fujitsu PRIMERGY RX2520 M4 Upgrade And Maintenance Manual

RX2520 M4 Upgrade and Maintenance Manual 289
Accessible drives
12.4.1.2 Removing the air grid
Figure 189: Removing the air grid
Ê Remove the 4 screws.
I Keep the 4 screws - they will be used again for fixing the LTO drive.
Ê Remove the air grid.
V CAUTION!
Save the dummy cover (air gird) for future use.
Always replace dummy modules into unused drive bays to comply with
applicable EMC regulations and satisfy cooling requirements.
