Fujitsu PRIMERGY RX2520 M4

408 Upgrade and Maintenance Manual RX2520 M4
Appendix A
16.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê "Shutting down the server" on page 48
Ê "Disconnecting the power cord" on page 49
Ê Take the system down to its minimum startup configuration.
Ê "Connecting the power cord" on page 59
Ê Connect a display to the server.
Ê "Switching on the server" on page 60
Field Replaceable Unit
(FRU)
Component Notes
System board no TPM or expansion cards installed
CPU with CPU heat sink installed in CPU slot CPU1
1 memory module installed in DIMM slot 1A
Front panel module
PSU installed in PSU bay PSU1
Table 4: Minimum startup configuration - components
Cable Notes
Front panel cable
Power cable
Table 5: Minimum startup configuration - cables
