26RX2520 M4
AccDrv_RDX
Cable plan
RDX PWR
RDX Data
RDX
C31
Systemboard
D3386
USB3.0 FRONT
PWR ODD
PWR4
PWR3
PWR2
FRONTPANEL1
SATA 4-7
PWR EXT
PWR CTRL
PWR MAIN
FP2
SATA ODD
USB 3.0 INT1
COM1
OOB FRONT
SATA 0-3
PWR1
ROC
C41
