196 Upgrade and Maintenance Manual
RX2520 M4
Expansion cards and backup units
9.1 Basic information
Figure 102: PCI slot overview - system board
SERIAL
SATA OD
PSU1
JP2
JP1
Slot OCP module
Micro
SD
SSD2
M.2
M.2
SSD1
TPM
iRMC
S5
LAN
Management
VGA
LAN 1
LAN 1/M
USB 3.0
VPP
VPP
LAN 1
LAN 2 /
USB 3.0
Slot 9 (CPU 2)
Slot 8 (CPU2)
Slot 2 (CPU 1)
Slot 1 (CPU 1)
Slot 4 (CPU 1)
Slot 3 (CPU 1)
JP7
JP8
Buzzer
iRMC
S5
Battery
VROC
