Fujitsu PRIMERGY RX2520 M4 Upgrade And Maintenance Manual

3RX2520 M4
List of used cables
Cable plan
Ref.
Part number
Name
Routing
Standard Cables
C1
T26139-Y4015-V301
CBL FRONT PANEL
Basic Cabling
C2
T26139-Y3999-V508
CBL_USB30_580
Basic Cabling
C3
T26139-Y4028-V304
CBL SATA 850
AccDrv_ODD
C5
T26139-Y4042-V6
CBL FLEXP 22PL 560
Basic Cabling
C6
T26139-Y3589-V410
CBL SERIAL 150
COM ext
C7
T26139-Y4015-V605
CBL_SMB_4XBP
OOB Cabling 4/8x3.5"
OOB Cabling 8/16/24x2.5"
OOB Cabling 8/12/16x2.5" PCIeSSD
C8
T26139-Y4030-V5
CBL_PWR_24P_24P
Basic PDB red PSU
C9
T26139-Y4030-V6
CBL_PWR_10P_10P
Basic PDB red PSU
C10
T26139-Y4027-V6
CBL_SMB_PDB_SYSB
Basic PDB red PSU
Power Cables
C11
T26139-Y3959-V312
CBL_PWR_4P_6P
Power Cabling 4/8x3.5"
Power Cabling 12x3.5"
Power Cabling 8/16/24x2.5"
Power Cabling 8x2,5" + 4x2.5" PCIeSSD
C13
T26139-Y3959-V354
CBL_PWR_ EXP_200
Power Cabling 8/16/24x2.5"
C14
T26139-Y4031-V102
CBL_FBU30_320
RAID SAS - TFM FBU02
C15
T26139-Y4031-V107
CBL_TFM_EP540_550
RAID EP5x0 - TFM FBU345 - HDD Signal
C16
T26139-Y3986-V302
CBL PWR 2CO 400
AccDrv_ODD
C41
T26139-Y4029-V1
CBL PATA Dev PWR
AccDrv_RDX
C42
T26139-Y3959-V311
CBL_PWR_4P_2x4P
Power Cabling 8x2,5" + 4x2.5" PCIeSSD
