266 Upgrade and Maintenance Manual RX2520 M4
Accessible drives
12.1 Basic informations
Mounting order for accessible drives in the front panel cage
The PRIMERGY RX2520 M4 server offers:
– one 5.25-inch accessible drive bays for ODDs
– one bay (optional) for a LTO drive or a RDX drive
I LTO drive or RDX drive are not available for 3.5-inch HDD versions.
Figure 162: Accessible drive in front panel module 3.5-inch HDD version
Figure 163: Accessible drives in front panel module 2.5-inch HDD version
1 ODD 2 RDX drive
LTO drive
