Fujitsu PRIMERGY RX2520 M4 Upgrade And Maintenance Manual

336 Upgrade and Maintenance Manual RX2520 M4
Front panel
13.4.2.2 Removing the ID card holder
Ê Remove the backplane 3 see "Removing the 2.5-inch HDD backplane" on
page 141.
Ê Remove the ID card, see figure 273 on page 388.
Figure 236: Removing the ID card holder (A)
Ê Press the ID card holder down (1) and push it in the direction of the arrow (2).
Figure 237: Removing the ID card holder (B)
