Indicator Status Description
A - Identification
blue on
The server has been highlighted using
ServerView Operations Manager, iRMC web
interface or the ID button on the front panel
for easy identification.
blue flashing
The server has been highlighted for easy
identification using the iRMC (AVR) with
disabled local VGA output.
B - CSS
(Customer Self
Service)
off No critical event detected (CSS component).
orange on Prefailure event detected (CSS component).
orange flashing CSS component failure detected.
C - GEL
(Global Error
LED)
off
No critical event detected (non CSS
component).
orange on
Prefailure event detected (non CSS
component).
orange flashing
Non CSS component failure detected.
Possible causes:
– System is out of the specified
temperature range
– Defective sensor
– CPU error
– Error detected by server management
software
F - Controller off Controller okay
orange on Controller failure (PCI card installed on
riser card)
G - CPU off CPU okay
orange on CPU failure
H - Memory off Memory module running
orange on Memory module failure
I - iRMC off iRMC S5 inactive
green flashing iRMC S5 okay
K - System fan off System fan running
orange on System fan failure
L - Battery orange on Battery failure
