TX300 S7 / RX350 S7 Upgrade and Maintenance Manual 223
Hard disk drives / solid state drives
7.2.7 Replacing a 2.5-inch HDD / SSD module
V CAUTION!
● Only remove an HDD / SSD module during operation if the drive is
not currently being accessed. Observe the indicators on the
HDD / SSD module, as described in the "PRIMERGY
TX300 S7 / RX350 S7 Server" operating manual".
● Under no circumstances should you remove an HDD / SSD module
while the system is in operation if you are not sure that the drive is
operated by a RAID controller and belongs to a disk array that is
operating in RAID level 0, 1, 1E, 10, 5, 50, 6 or 60.
An HDD / SSD module can only be replaced during operation in
conjunction with a corresponding RAID configuration.
● All HDD / SSD modules (drives) must be uniquely identified so that
they can be reinstalled in their original mounting locations later. If this
is not done, existing data can be lost.
7.2.7.1 Required tools
● Preliminary and concluding steps: tool-less
● Replacing a 2.5-inch HDD / SSD module: tool-less
Customer Replaceable Units (CRU)
Average task duration: 5 minutes
