Fujitsu PRIMERGY TX300 S7 - Mounting the Second 3.5-Inch HDD Backplane

TX300 S7 / RX350 S7 Upgrade and Maintenance Manual 301
Hard disk drives / solid state drives
7.3.10.5 Mounting the second 3.5-inch HDD backplane
Figure 176: Adding HDD mounting rails
Ê Add eight HDD mounting rails to the HDD bays and HDD bay top cover as
shown (see arrows).
