Fujitsu PRIMERGY TX300 S7 - 17 Appendix; Mechanical Overview; Server Front

TX300 S7 / RX350 S7 Upgrade and Maintenance Manual 941
17 Appendix
17.1 Mechanical overview
17.1.1 Server front
2.5-inch HDD / SSD model
Figure 665: PRIMERGY TX300 S7 / RX350 S7 front - 2.5-inch HDD / SSD model
Pos. Component Reference
1
2.5-inch hard disk drives /
solid state drives / dummy
modules
"8x 2.5-inch HDDs (2 SAS backplanes)" on
page 200
2
Optical disk drive /
5.25-inch dummy module
"Accessible drive bays" on page 652
3ID card "Opening the server" on page 79
