TX300 S7 / RX350 S7 Upgrade and Maintenance Manual 701
Accessible drives
Ê Close the side / top cover as described in section "Mounting the top cover"
on page 115 (rack server) or "Mounting the side cover" on page 122 (tower
server).
Ê When working on a rack-mounted server, secure it in the rack as described
in section "Sliding the server into the rack" on page 132.
If the server has been completely removed from the rack for maintenance
purposes, reinstall and secure it in the rack as described in section
"Mounting the server in the rack" on page 130.
Ê Reconnect the AC power cords to the power supply units and secure them
with PSU cable brackets as described in section "Connecting the server to
the mains" on page 133.
12.5.2 Removing a slimline ODD or LSD
12.5.2.1 Required tools
● Preliminary and concluding steps: tool-less
● Removing a slimline ODD or LSD:
– Phillips PH2 / (+) No. 2 screw driver
12.5.2.2 Preliminary steps
Before removing a slimline ODD or LSD, perform the following steps:
Ê Remove all backup and optical disk media from backup and optical disk
drives as described in section "Removing backup and optical disk media" on
page 144.
Ê Shut down the server as described in section "Shutting down the server" on
page 71.
Upgrade and Repair Units (URU)
Average task duration: 10 minutes
