TX300 S7 / RX350 S7 Upgrade and Maintenance Manual 519
Expansion cards and backup units
Figure 356: Installing the GPGPU air duct top cover (2 cards)
Ê The bent out blind cover rests against the second GPGPU card as shown.
9.5.1.12 Installing the system air duct
Figure 357: Installing the rear fan holder
