Ê Run the GPGPU power cables through the semicircular cable inlet in the
GPGPU air duct base:
Figure 308: Installing the GPGPU air duct top cover (A)
A cable routing with with one GPGPU / coprocessor card
B cable routing with with two GPGPU / coprocessor cards
GPGPU air duct top cover (C26361-K644-C872)
I The part number does not apply to the Japanese market.
A Slot for Intel Xeon Phi mounting bracket
B Slot for Nvidia TESLA K20 mounting bracket
