11.1.2 Processor locations
Figure 365: CPU locations on system board D2949
11.2 Installing processors
V CAUTION!
Processors are extremely sensitive to electrostatic discharge and must
be handled with care. After a processor has been removed from its
protective sleeve or from its socket, place it upside down on a
nonconducting, antistatic surface. Never push a processor over a
surface.
Upgrade and Repair Unit
(URU)
Average task duration:
20 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
