7.2.8.2 Removing a 2.5-inch HDD / SSD module
Ê Remove the HDD / SSD module to be replaced from the server as described
in section "Removing a 2.5-inch HDD / SSD module" on page 211.
7.2.8.3 Installing a 2.5-inch HDD / SSD module
Ê Install the new HDD / SSD module into the empty drive bay as described in
section "Installing 2.5-inch HDD / SSD modules" on page 207.
7.2.8.4 Concluding steps
Ê When working on a tower server, close the HDD bay cover as described in
section "Installing accessible drive and HDD bay covers" on page 105.
Ê Please observe the notes on RAID rebuild in section "Performing a RAID
array rebuild" on page 153.
7.2.9 Replacing a 2.5-inch HDD SAS backplane
7.2.9.1 Preliminary steps
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê Remove all HDD modules from the server as described in section
"Removing 2.5-inch HDD / SSD modules" on page 210.
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
Upgrade and Repair Unit
(URU)
Average task duration:
15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
