300 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Hard disk drives / solid state drives
7.4.6.3 Installing accessible drive dummy covers
Ê Install accessible drive filler covers into empty drive bays as described in
section "Accessible drive filler covers" on page 94.
Ê Install accessible drive covers into the front cover as described in section
"Accessible drive covers" on page 96.
7.4.6.4 Concluding steps
Ê "Installing the system fan holder" on page 331
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê "Connecting the server to the mains" on page 118
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task: "Resuming BitLocker functionality" on page 152
7.4.7 Replacing the 4x 3.5-inch HDD extension box
7.4.7.1 Preliminary steps
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê Remove all HDD modules from the HDD extension box as described in
section "Removing 3.5-inch HDD modules" on page 258.
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: tool-less
