11.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 125
Ê "Disabling SVOM boot watchdog functionality" on page 127
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Bring the server to its horizontal position.
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
Ê "Removing the system air duct" on page 81
11.2.2 Installing a processor
I This description applies to the following procedures:
– Installing the second CPU in a mono-processor configuration
– Transferring a CPU after replacing the system board (see section
"Swapping processors" on page 695)
Figure 366: Opening socket release lever 1
