Ê Carefully lower the fan holder into the chassis (1) until the two locking tabs
(2, see close-ups) engage.
Ê Ensure that the connectors on the fan modules properly engage with the fan
connectors on the system board.
8.2.2.4 Concluding steps
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
8.3 Rear fans
Two optional hot-pluggable rear fan modules can be added to the system for fan
redundancy.
V CAUTION!
When equipping rear fans, ensure to always install both rear fan modules
in order to satisfy cooling requirements. Operation with only one rear fan
module is not possible.
8.3.1 Installing rear fan modules
8.3.1.1 Preliminary steps
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
Customer Replaceable Unit
(CRU)
Average task duration:
5minutes
Tools: tool-less
