7.4.9.4 Concluding steps
Ê "Installing the system fan holder" on page 331
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê "Connecting the server to the mains" on page 118
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task: "Resuming BitLocker functionality" on page 152
7.4.10 Replacing the 8x 2.5-inch HDD extension box
7.4.10.1 Preliminary steps
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê Remove all HDD modules from the HDD extension box as described in
section "Removing 2.5-inch HDD / SSD modules" on page 210.
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: tool-less
