12.7 Slimline ODD in 4x 3.5-inch HDD extension
box
12.7.1 Installing the slimline ODD
12.7.1.1 Preliminary steps
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
I The front cover only needs to be removed in order to remove
accessible drive dummy covers (see section "Removing accessible
drive dummy covers" on page 533). If the HDD extension box is
already installed in the server and will be removed in order to install
a slimline ODD or LSD module, skip this step.
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
Ê If the HDD extension box is already installed in the server, disconnect all
cables from the HDD backplane and remove the extension box as described
in section "Removing the 4x 3.5-inch HDD extension box" on page 299.
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
