12.7.2 Removing the slimline ODD
12.7.2.1 Preliminary steps
Ê "Removing backup and optical disk media" on page 129
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
I The front cover only needs to be removed in order to install
accessible drive dummy covers (see section "Installing accessible
drive dummy covers" on page 548). If the HDD extension box will be
reinstalled after removing the slimline ODD, skip this step.
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
12.7.2.2 Removing the 4x 3.5-inch HDD extension box
Ê Remove the 4x 3.5-inch HDD extension box from installation bays 1, 2 and
3 as described in section "Removing the 4x 3.5-inch HDD extension box" on
page 299.
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
