TX300 S8 / RX350 S8
Upgrade and Maintenance Manual
621
Front panel and ext
ernal connectors
Figure 487:
Mounting the f
ront LAN con
nector (B)
Ê
Carefully snap the front LAN cable connector into the mounting bracket (see
close-up).
13.2.1.5
Reassembling the fron
t p
a
nel module
Ê
"Mounting the front panel module cov
er" on page
609
13.2.1.6
Reinstalling the front p
anel modu
le
Ê
"Installing the front p
anel module" on p
age
61
1
620
622
