7.4.3 Removing the 2x 3.5-inch HDD extension box
7.4.3.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 125
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê Remove all HDD modules from the HDD extension box as described in
section "Removing 3.5-inch HDD modules" on page 258.
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
7.4.3.2 Removing the 2x 3.5-inch HDD extension box
Ê Remove all cables from the 2x 3.5-inch HDD extension box backplane.
Ê If applicable, remove all cables from the slimline ODD.
Ê If applicable, remove the LSD cable from system board connector SMB 1.
Ê Disengage the accessible drive locking bar as described in section "Opening
the accessible drive locking bar" on page 91.
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: tool-less
